Overview
The A-13S Diver's Watch
I'm currently building my own personal dive watch—one that reflects exactly what I believe a true tool watch should be.
It's a personal project, driven by passion rather than plans. If everything goes as hoped, and if I'm completely satisfied with the result, who knows...
There might even be a third A-13A one day.
Data Sheet
| Case | |
| AISI 316L stainless steel | |
| Full brushed case | |
| Diameter 41 mm, thickness 14 mm, lug to lug 48.5 mm | |
| Net weight without strap or bracelet | |
| Retaining-ring caseback construction | |
| Retaining ring with anti-seize barrier layer | |
| Double O-ring sealing system | |
| Caseback with anti-rotation notches | |
| Triple gaskets screw-down crown sealing system | |
| Water resistance tested to 600 m | |
| Bezel | |
| Unidirectional ceramic bezel | |
| 120-click action | |
| Smooth rotating bezel with FKM anti-slip, shock-absorbing ring | |
| AISI 316L bezel pip with Super-LumiNova® BGW9 and sapphire cap | |
| Viton O-ring AS560-125 for shock protection and better grip | |
| Movement | |
| SOPROD M100 | |
| Bidirectional automatic winding | |
| Regulated and tested in 5 positions | |
| 28,800 alternances per hour | |
| 25 jewels | |
| Approx. 42-hour power reserve | |
| Hacking seconds (stop-seconds for precise time setting) | |
| Crystal | |
| Sapphire crystal | |
| 3.10 mm thickness, slightly domed | |
| Internal anti-reflective coating | |
| Hands | |
| Based on the A-13A legacy (MIL-C-6499E) | |
| Filled with Super-LumiNova® BGW9 | |
| Dial | |
| Based on the A-13A legacy (MIL-C-6499E) | |
| Stepped chapter ring | |
| Applied numerals | |
| Super-LumiNova® BGW9 hour markers | |
| Strap and Buckle | |
| Proprietary black FKM rubber strap with signed keepers | |
| A-13A airfoil motif printed on the inner side | |
| Brushed and signed AISI 316L buckle | |
| Bracelet | |
| To be defined |
